InPlugin EV/PHEV Charging Cable
Built for Durability
| Electrical Parameters | |
|---|---|
| Power | ≤7kW |
| Current | ≤32A |
| Voltage | Single-Phase AC 85V-275V |
| Hardware Specifications | |
| Length | 5 meters |
| Material | Thermoplastic (Flame retardant grade UL94 V-0) |
| Cable Specifications | 3 × 6mm² + 1 × 0.75mm² |
| Plugs & Sockets | |
| Vehicle-Side Plug | SEA J1772 / Type-2 / GB/T |
| Power-Side Plug | SEA J1772 / Type-2 / GB/T |
| Operating Environment | |
| Operating Temperature | -35℃ to 55℃ |
| Waterproof Rating | IP66 |
FAQ
Extension Cable *1
EV Charging Cables and EV Charging Extension Cables serve different purposes and are designed differently, leading to important differences:
① Function and Purpose:
- EV Charging Cable:
Connects directly between the charging station and the electric vehicle (EV). It’s specifically built for efficient power transfer and precise communication between charger and car. - EV Charging Extension Cable:
Extends the length of an existing EV Charging Cable, offering flexibility when the standard cable length isn't enough.
② Compatibility and Safety:
Smart Chip Differences:
- EV Charging Cable:
Has a built-in proprietary communication chip (like a "translator") designed for specific charging protocols (e.g. Tesla NACS or SAE J1772). - EV Charging Extension Cable:
Uses a different type of chip (similar to translating a "foreign language"), which can result in:
Communication Errors: Chargers may fail to recognize the cable, stopping the charging process.
Potential Damage: Forced or incorrect connections might damage the charging ports on your vehicle.
③ Connector Design Differences:
- EV Charging Cable Port:
Standard length (~8 cm) connector suitable for direct charging station connections. - EV Charging Extension Cable Port:
Longer connector (~10.5 cm) with special features:
Dual Locking Mechanism: Provides extra grip and prevents accidental disconnection.
Guiding Bevel: Designed to avoid entanglement with other cables.
So, they cannot be used interchangeably.
Yes. The vehicle automatically locks the charging connector after the car is locked.
It comes with a 2-year warranty.
